PRG Mbox - Fixture Parameter Descriptions; Parameter Descriptions: Mbox Designer

190
MBOX® USER MANUAL
Fixture Sub-Fixture Parameter Description
Global Master
Intensity Master intensity of all video output
Control Selects control Macros and HUDs
Control Selector
Used with Control to select specic modes for
macros/HUDs
Pixel Mapping
Intensity
Master intensity of all pixel mapping output
Master Volume Master volume for all audio output
Light
(5 required)
Intensity Intensity of the light
Red Red Subtractive
Green Green Subtractive
Blue Blue Subtractive
Ambience Beam spread - spot to full ambient
Bearing Horizontal orbit around center of 3D space
Elevation Vertical orbit around center of 3D space
Parameter Descriptions: Mbox Designer
The data in these charts is organized by product version. Fixtures are listed in basic patch order and show detail of their
component sub-xtures. Fixture quantities (required or optional) are noted. Parameters are listed in patch order.
FIXTURE PARAMETER DESCRIPTIONS
