MBOX® USER MANUAL
Keystone Blend Mode/Curve
Note 1: A Keystone Mode/Curve value of 0 enables the advances toolset that is accessed through the user interface of
the Mbox Remote application
Note 2: When the value is set to 0, settings from the advanced toolset will negate the standard corner, edge-blend, and
linearity controls, but not the Output Geometry controls.
Value Mode Blend Curve
Grid
Overlay
Controls
0 Disable DMX Keystone controls
1,2
n/a N
Keystone/Warp is set from Mbox
Remote
1 Use DMX controls Linear N X/Y corner controls
2 Use DMX controls Raised Cosine N X/Y corner controls
3 Use DMX controls Sine N X/Y corner controls
4 Use DMX controls No Blending N X/Y corner controls
11 Use DMX controls Linear Y X/Y corner controls
12 Use DMX controls Raised Cosine Y X/Y corner controls
13 Use DMX controls Sine Y X/Y corner controls
14 Use DMX controls No Blending Y X/Y corner controls
Shutter Mode/Shapes
Value Shape Notes
0-9 Disabled
10-19 Moving Light Mode
Separate controls for each end of shutter. If both controls are at
0, the shutter disappears.
20-29 Leko Mode
Distance and angle controls. If distance is zero, the shutter
disappears.
30-39 Iris Mode
A round iris. Scale is used to adjust the size of the iris. No other
controls.
40-49 Blob mode
A bezier curve is drawn touching the midpoints of the
quadrilateral formed by the Leko mode shutters.
