PRG Mbox - Combined Effects

206
MBOX® USER MANUAL
Value Effect Description Mod 1 Mod 2 Mod 3 Mod 4 Mod 5
0 NONE no effect
1 Hue simple hue adjustment hue angle
2 Hue & Saturation
combines hue and
saturation
hue angle
saturation
(127=def.)
3 Gamma gamma adjustment gamma
4 Exposure exposure adjustment exposure
5 Monochrome
converts to grayscale,
adds color
amount red green blue
6 Sepia Tone
converts to sepia tone
amount
7 Invert color invert
8 Hilight & Shadow adjusts tonal mapping radius
hilight
amount
shadow
amount
9 Vibrance adjusts saturation amount
10 Solarize solarize effect intensity
11 X-Ray inverted grayscale intensity
12 Color Switch
RGB becomes RBG/
BGR/BRG/GBR/GRB
intensity mode
13 Color Shift
dynamic color shift (sine
function)
mixer range speed
14 Posterize reduce color space amount
15 Bloom soften edges, add glow intensity radius
16 Gloom dulls highlights intensity radius
17 Sharpen
increases detail by
sharpening
sharpness
18 Unsharp Mask
increases contrast
at edges to enhance
details
intensity radius
19 Median
reduce noise with
median calculation
20 Black Threshold
renders dark areas as
true black
intensity threshold
21
Color Brightness
and Contrast
can be used instead of
built-in controls
red
(127=def.)
green
(127=def.)
blue
(127=def.)
brightness
(127=def.)
contrast
(127=def.)
22-31 Reserved
32 Blur - Quick simple/quick image blur mixer amount
33 Blur - Quick X quick blue on X axis mixer amount
34 Blur - Quick Y quick blur on Y axis mixer amount
35 Blur - Box box-shaped convolution radius
36 Blur - Gaussian sophisticated/slow blur radius
37 Blur - Zoom
blurs outwards from
point in image
size x position y position
Combined Effects
