PRG Mbox - Discrete Values for Slotted Parameters; Global Master Control Channel

204
MBOX® USER MANUAL
Value Command Notes
Macro Trigger
Action
Master Control Selector
10-19 Output Stats HUD
Shows output size, re-
fresh, rendering stats
n/a n/a
20-29 Performance HUD
Shows overall perfor-
mance, layer playback
and rendering
n/a n/a
30-39 Version HUD
Shows build version,
share name
n/a n/a
40-49
Lights/Master/Shutter/
Keystone HUD
Shows control input
values - v3 format
n/a n/a
50-54 Texture HUD - Layers 1-6
Shows control input
values - v3 format
n/a n/a
55-59 Texture HUD - Layers 7-12
Shows control input
values - v3 format
n/a n/a
60-64
Layer Effects HUD - Layers
1-6
Shows control input
values - v3 format
n/a n/a
65-69
Layer Effects HUD - Layers
7-12
Shows control input
values - v3 format
n/a n/a
70-71
Raw Control Input HUD
Universe A
n/a n/a
72-73
Raw Control Input HUD
Universe B
n/a n/a
74-75
Raw Control Input HUD
Universe C
n/a n/a
76-77 SADI Stats n/a n/a
80-89 Show PixMap Context View
80 = All contexts,
81-89 = contexts 1-9
n/a n/a
110-
111
Show Timecode HUD
(Center)
n/a n/a
112-
113
Show Timecode HUD (Top
Right)
n/a n/a
114-
115
Show Timecode HUD (Top
Left)
n/a n/a
116-
117
Show Timecode HUD
(Bottom Right)
n/a n/a
118-
119
Show Timecode HUD
(Bottom Left)
n/a n/a
201 Run Script Value then 0 0-255 for script index number
202 Change Pixel Mapping File Value then 0 0-255 for cong index number
203 Cancel Keyboard HUD Value then 0 n/a
220 Show Object Mesh
Shows mesh on all
objects
n/a 0 = all, 1-24 = by layer number
222 Show Edge-blend guides
Shows guides for blend
areas
n/a n/a
Global Master Control Channel
DISCRETE VALUES FOR SLOTTED PARAMETERS
