PRG Mbox - Page 215

205
MBOX® USER MANUAL
Value Command Notes
Macro Trigger
Action
Master Control Selector
224 Show Single Mix
Shows outline of one
mix at a time
n/a Mix index number
225 Show All Mixes
Shows outlines of all
mixes at the same time
n/a n/a
226 Show Output Mixes Only
Shows outlines of out-
put mixes only
n/a n/a
227 Show Keystone Mesh Shows keystone mesh n/a 0 = all, 1-32 = by output number
230 File Sharing On Value then 0 n/a
231 File Sharing Off Value then 0 n/a
232 Remote Management On Value then 0 n/a
233 Remote Management Off Value then 0 n/a
234 Backup Mode On
Disables Layer Sync
and PixMap output
Value then 0 n/a
235 Backup Mode Off
Enables Layer Sync and
PixMap output
Value then 0 n/a
240 Rescan Media Library
Hold 3-sec then
0
n/a
241 Audio Offset
Sets audio playhead
offset in relation to
video playhead in 20mS
increments
Immediate
0-126 = audio late, 127 = de-
fault, 128-255 = audio ahead
244 Pixel Mapping Output Enable
Turn ON pixel mapping
engine and output
Value then 0 n/a
245 Pixel Mapping Output Disable
Turn OFF pixel mapping
engine and output
Value then 0 n/a
246 Pixel Mapping Masking Off
Masked xtures use
normal output values
Value then 0 n/a
247 Pixel Mapping Masking On
Masked xtures’ output
forced to 0
Value then 0 n/a
250 Quit Mbox Application
Hold 3-sec then
0
n/a
251 Shutdown Computer
Hold 3-sec then
0
n/a
252 Restart Computer
Hold 3-sec then
0
0-255 for script index number
253 Restart Mbox Application
Hold 3-sec then
0
0-255 for cong index number
254 Restart Daemon Application
Hold 3-sec then
0
n/a
Global Master Control Channel continued...
