217
MBOX® USER MANUAL
Play Speed
Value Play Mode
0 Paused
1 - 126 Increasing speeds from paused to normal
127 Normal speed = movie fps
128 Compensated speed - match output refresh rate (with +/- ~5% deviation)
129 - 255 Increasing speeds from normal to 4x normal
Sync Stream
Value Stream Notes
0 Layer to Layer
Used for sending/receiving sync to/from layer of same
number on another Mbox server
1 Stream 1
Used for sending/receiving sync to/from any layer which is
set to same stream number
2-32 Streams 2 thru 32... As above...
33-96 Streams 33-96
All versions of Mbox can listen to 96 streams, but cannot
output above their limit. See note below.
Note: Depending on the product version (Designer/Studio/Mini) there are limits placed on the number of sync stream
outputs. This table represents the full list of available streams for Mbox Designer. Studio has 16 sync stream, and Mini
has 8. Therefore, valid Sync Stream output values will be limited to those maximums for each, but all versions can
receive up to 96 streams.
Aspect Control
Value Mode
0 Square pixels (default)
1-126 Ratios scaling from 1:4 to 1:1
127 1:1 ratio
128-255 Ratios scaling from 1:1 to 4:1
Frame Blending Control
A value of 0 = no frame blending (or more accurately, blend time = 0). The range of 1 - 255 = variable frame blend time,
as a proportion of the normal frame time. This is a square-law control, and 50% blend time is achieved at DMX 210, 25%
blend time at DMX 165.
