207
MBOX® USER MANUAL
Value Effect Description Mod 1 Mod 2 Mod 3 Mod 4 Mod 5
38 Blur - Motion blurs along variable axis radius angle
39-43 Reserved
44 Key - Black dark areas transparent intensity threshold
45 Key - White white areas transparent intensity threshold
46 Key - Red red areas transparent intensity threshold
47 Key - Green green areas transparent intensity threshold
48 Key - Blue blue areas transparent intensity threshold
49 Key - Invert White
all but white areas
transparent
intensity threshold
50 Key - Invert Red
all but red areas
transparent
intensity threshold
51 Key - Invert Green
all but green areas
transparent
intensity threshold
52 Key - Invert Blue
all but blue areas
transparent
intensity threshold
53 Key - RGB
specic RGB color
transparent
intensity threshold red green blue
54 Key - HSV
specic HSV color
transparent
intensity threshold hue saturation value
55 Key - XY
specic XY location
color transparent
intensity threshold x position y position
56 Key - Luma
brighter areas
transparent
intensity threshold
57 Key - Luma Inverse darker areas transparent intensity threshold
58
Key - Chroma
2017
alternate to Key - RGB
effect
intensity threshold red green blue
59 Alpha Matte
creates matte based on
transparency of layer
mode
60-63 Reserved
64 Crop - Circular
circular image crop with
soft edge
mixer size edge
65 Crop - Rectangular
rectangular image crop
with soft edge
mixer size edge
66 Crop - Circular XY
circular image crop with
soft edge & xy position
adjust
mixer size edge
x position
(127=def.)
y position
(127=def.)
67
Crop - Rectangular
XY
rectangular image crop
with soft edge & xy
position adjust
mixer size edge
x position
(127=def.)
y position
(127=def.)
68 Crop - Oval XY
oval image crop with
soft edge & xy position
adjust
size edge
x position
(127=def.)
y position
(127=def.)
aspect
69 Crop - Horizontal horizontal 90° shutters mixer width
position
(127=def.)
Combined Effects continued...
