Mbox Mini can have six Output Masters:
+ By default, Mbox Mini has one assigned Output Master which includes all of the functionality – base, one effect,
keystone, and shutter – and which requires 40 channels. At least one Output Master is always required.
+ Patched Output Masters start on the rst control universe (offset 0) for the server, immediately after the Global
Master xture - at address 6.
+ Six Output Masters will t into the rst universe with up to ve playback layers. If more than four Output Masters are
used, the sixth Layer must be placed on the next consecutive universe.
+ Universe Offset 0 = Output Masters 1 – 6 and Layers 1 – 5 (Layers 1 – 6 if less than ve Output Masters are used)
+ Universe Offset +1 = Layer 6 if more than four Output Masters are used.
+ The controls for playback layers always start on the rst control universe (offset 0), and Layer six will be moved up
one universe (to offset +1) if more than four Output Masters are used.
+ If an Output Master is assigned to an output but no data is available on the corresponding channels, then the output
will not be visible as it will have been dimmed to black.
