194
MBOX® USER MANUAL
Fixture Sub-Fixture Parameter Description
Layer
continued...
Base
continued...
Z Spin Adjusts spin of content around the Z axis
X Spin Adjusts spin of content around the X axis
Y Spin Adjusts spin of content around the Y axis
Mix Select Assigns content on layer to a mix
Mix Mode Sets the mode for the selected mix
Blend Mode Selects a 2D blending mode
Draw Mode Selects a 2D draw mode (stenciling)
Image Remap
Selects image remapping conguration for the
layer
FX
Effect 1 Select First 2D effect applied to the layer
Modier 1a First modier
Modier 1b Second modier
Modier 1c Third modier
Modier 1d Fourth modier
Modier 1e Fifth modier
Effect 2 Select Second 2D effect applied to the layer
Modier 2a First modier
Modier 2b Second modier
Modier 2c Third modier
Modier 2d Fourth modier
Modier 2e Fifth modier
Effect 3 Select Third 2D effect applied to the layer
Modier 3a First modier
Modier 3b Second modier
Modier 3c Third modier
Modier 3d Fourth modier
Modier 3e Fifth modier
Effect 4 Select Fourth 2D effect applied to the layer
Modier 4a First modier
Modier 4b Second modier
Modier 4c Third modier
Modier 4d Fourth modier
Modier 4e Fifth modier
Volume Volume Audio volume for layer
Timecode
Hours Hours value for DMX timecode
Minutes Minutes value for DMX timecode
Seconds Seconds value for DMX timecode
Frames Frames value for DMX timecode
Parameter Descriptions: Mbox Designer continued...
