MBOX® USER MANUAL
Value Effect Description Mod 1 Mod 2 Mod 3 Mod 4 Mod 5
186 Cartoon cartoon effect mixer line width
color re-
duction
187 Shaded Material
luma of input creates a
relief map
layer scale
188 Histogram height low limit high limit
189 Roll - XY horizontal & vertical roll mixer
x amount
(127=def.)
y amount
(27=def.)
190 Pillowblocks eggcrate mask effect mixer multiplier size brightness
191
Triangle
Kaleidoscope
geometric distortion
using triangles
size rotation decay
x
(127=def.)
y
(127=def.)
192-
220
Reserved
221 LRBT Shutter mask sides of layer left right bottom top
222 Move Center
offsets rotational center
of image
x
(127=def.)
y
(127=def.)
223 Shake 3D X/Y shake effect x y
224 Strobe strobe effect off time on time
225 Reserved
226
Texture Scale/
Rotation
adjusts scale and
rotation of texture on
gobos
scale rotation
227
Texture X/Y
Position
adjusts x/y position of
texture on gobos
x
(127=def.)
y
(127=def.)
228
X/Y Position &
Scale Damping
damps movement of
parameters in 1/30sec
increments
xy posi-
tion
scale
229
Z Rotation & Scale
Damping
damps movement of
parameters in 1/30sec
increments
z rotation scale
230 Texture Flip
ips texture drawing on
objects
mode
6
231 Spin drop shadow effect
z spin:
0=home,
1-126=rev,
127=stop,
128-
255=fwd
x spin:
0=home,
1-126=rev,
127=stop,
128-
255=fwd
y spin:
0=home,
1-126=rev,
127=stop,
128-
255=fwd
Combined Effects continued...
