219
MBOX® USER MANUAL
Texture Transitions continued...
Value Transition Description
38 Vertical Bars 20 vertical bars, hard edge
39 Vertical Bars + Blend 20 vertical bars, soft edge
40 Circle Center circle out from center
41 Circle Center + Blend circle out from center, blended edge
42 Concentric Circles circles out from center, blended edges
43 Push Right new image pushes in left to right
44 Push Left new image pushes in right to left
45 Push Down new image pushes in top to bottom
46 Push Up new image pushes in bottom to top
47 Split Right outgoing image splits and slides to the right
48 Split L/R Center outgoing image splits and slides left & right from the center
49 Split Down outgoing image splits and slides down
50 Split Up outgoing image splits and slides up
51 Split U/D Center outgoing image splits and slides up & down from the center
52 Split XY outgoing image splits and slides outwards from the center
53 Bar Swipe Right outgoing image slides to the right in strips
54 Bar Swipe Left outgoing image slides to the left in strips
55 Bar Swipe Up outgoing image slides upwards in strips
56 Bar Swipe Down outgoing image slides downwards in strips
57 Page Curl 1 page corner curls from bottom-right to top-left
58 Page Curl 2 page corner curls from top-right to bottom-left
101-110 Custom Hard-edge Wipe 1-10
1
hard-edge wipe using custom grayscale le
111-120 Custom Soft-edge Wipe 1-10
2
hard-edge wipe using custom grayscale le
255 Object Dissolve fade out on current object, fade in on new object
Note 1: The custom hard-edge transitions require JPEG still image les to be placed at /Mbox/plugins/images/grayscale
with each image having an index number 1 through 10.
Note 2: The custom soft-edge transitions require JPEG still image les to be placed at /Mbox/plugins/images/grayscale
with each image having an index number 11 through 20.
