Prontonet User’s Manual v410 20
LED on: Line connected
LED blinking: Call in progress or incoming call detected
The Decoder can be in one of the following states:
 FRAMED: Audio Synchronised. The displays shows the word “FRAMED”:
 SEARCH Searching for synchronisation. The displays shows the word
“SEARCH”:
 The Decoder status information only appears if the line is connected
 If the line is showing an IDLE status, an indicator code will show the cause of the
last disconnection below. In Appendix B you will find explanations for each of these
codes.
 When the lines are not connected the selected NET will be shown.
 When the ProntoNet is operating as a DUAL codec, there will be two independent
Decoders, one for each line. In all other cases information will only show on the first
line of the display as there will be only one Decoder working (even if there are two
communication lines connected).
 When the lines are connected the direction of the arrow will indicate if the unit made
or received the connection.
The backup can be in one of the following states:
 DISABLED: The display doesn’t show any information about it.
L1:IDLE (0) IP
L2:NOT AVAILABLE
L1:IDLE (0) IP
L2:NOT AVAILABLE
L1:IDLE (0) IP
L2:NOT AVAILABLE
L1´ CONNECTED FRAMED
L2: NOT AVAILABLE
L1:CONNECTED FRAMED
L2:DOWN
L1:CONNECTED SEARCH
L2:DOWN
