Prontonet User’s Manual v410 47
LINE1 ANSWER MODE
MANUAL{AUTO}
SET X21 PORT
{64}128 192 256 384
SET RS232 PORT
{PORTA}PORTB
SET RS232 PORTA >>
{300}1200 2400 4800
<< SET RS232 PORTA
1200 2400 4800 9600
ANS:
For communication Line 2 the options are laid out in the same way.
Configuration of the X21 port.
The configuration of the X21 port consists of selecting the operational speed.
The options available are: 64, 128, 192, 256 and 384 Kbps.
Configuration of the RS232 ports
The RS232 ports are there for the transmission/reception of auxiliary data. Here
the operational speed is set for each one.
Port B is only available if the unit is working in dual mode, i.e. each line is
working independently.
