Prontonet User’s Manual v410 50
BACKUP TIMER
{DOWN}UP
BACKUP TIMER DOWN
(10 - 255):10_
BACKUP TIMER UP
(10 - 255):10_
FAN MENU
{OFF}AUT
AUX.DATA MENU
{RS232}GPIO
TIMER: This option is only available when configured as MASTER. This
option allows to program the timers to decide when the unit goes to
backup mode or when the unit goes to normal mode again.
In the Down timer, the user programs the time the unit will need to decide
that the main line is dropped. The Up timer is the main line recovering
time . The minimum time can be programmed is 10 sc and the maximum
255sc. This option is only available if the unit is working as MASTER.
FAN: To disable the fan.
In AUT mode fan is temperature controlled and will switch itself on and off
automatically as required.
AUXDATA: This option allows to configure if the decoder will be able to
receive ancillary data or not.
