Device Manual CANlink wireless
Getting started
PROEMION GmbH | Phone: +49 661 9490-600 | Fax: +49 661 9490-666 | info@proemion.com | proemion.com | Version 1.0 52
© 2016RM MICHAELIDES● VX.X ● Device Manual CANlink 5000 series © 2016RM MICHAELIDES● VX.X ● Device Manual CANlink 5000 series © 2016 PROEMION GMBH > 1.0 EN > Device Manual CANlink wireless 3000 series
CREATING AND CHECKING A SECOND TEST MESSAGE
1. In the same way as for the Generator CV, specify a new generator with the following
parameters:
Name Entry
Generator Name
Generator CLW
ID 124
Data Type UInt8
First Data Byte to generate Byte 1
Choose Generator Triangle, Cyclic, Cycletime 10
Generator CLW parameters
2. Switch to the first instance of RM CAN-Device Monitor.
3. In the same way as for the I
NDICATOR CLW, specify an indicator with the following
parameters:
Name Entry
Indicator Name Indicator CV
ID 124
Data Type UInt8
First Data Byte to trigger Byte 1
Choose Indicator Triangle
Indicator CV paramters
4. Switch to the second instance of RM CAN-Device Monitor.
5. In the G
ENERATOR CLW window, click the SEND button.
 This starts the G
ENERATOR CLW.
