Range assignment table
Starting value
Possible values
Increment Lower value Upper value
Lower signal
limit
4 mA 0 mA
4 mA
Assigned
measuring
range*
0 - 100.0 % 0.1 % -5 % 105 %
0 - 20.00 mA 0.01 mA -1.00 mA 21.00 mA
*= for other measuring ranges see
Ä Table on page 105
9.5 Description of All Standard Signal Measured Values/Measured
Variables
Possible values
Measured vari‐
able
Increment Lower value Upper value Measuring
range*
Measuring
signal
0.1% -5,0 % 105,0 % 100 %
0.01 mA -1.00 mA 21.00 mA 20 mA
Filling level 0.01 m 0.00 m 31.50 m 30 m
0.1 % 0.0 % 105,0 % 100 %
Pressure 0.001 bar 0.000 bar 1.050 bar 1.000 bar
0.001 bar 0.000 bar 5.250 bar 5.000 bar
0.01 bar 0.00 bar 10.50 bar 10.00 bar
0.1 bar 0.0 bar 105.0 bar 100.0 bar
0.1 psi 0.0 psi 105.0 psi 100 psi
1 psi 0 psi 1050 psi 1000 psi
* Maximum set point that can be set
Measured Variables and Operating Menus for the Standard Signal General
105
