10.1 Pumps
CAUTION!
Observe the operating manual for the pump
Possibility of damage to the pump. Faults in the process.
– The pump must be set to "External Control" operating mode
–
Observe the maximum stroke rate for the pump
– Possibly switch off any stroke memories in the pump controller
– The maximum stoke rate for the pump can be found in the operating manual for
the pump
– Setting a stroke rate on the controller, which is higher than the actual pos‐
sible maximum stroke rate of the pump, can lead to hazardous operating
conditions
NOTICE!
Maximum pump frequency
The pumps are activated in accordance with the actuating variable up to the respec‐
tive maximum frequency of the pump.
Only with pumps for control
pumps
setting ?
control
pump 1
pump 2
dosing pump max
.
pump 1: 180
pump 2: 180
pulse/minute
A0021_GB
Fig. 55: Pumps
Operating Menus Independent of Measured Variables
114
