3 D1Cb mounting
n User qualification, mechanical
mounting: trained qualified personnel,
see
Ä Chapter 1.2 ‘Users' qualifica‐
tions’ on page 10
n User qualification, electrical installa‐
tion: Electrical technician, see
Ä Chapter 1.2 ‘Users' qualifications’
on page 10
NOTICE!
Mounting position and conditions
– Ensure that there is unimpeded
access for operation
–
Secure, low-vibration fixing
– Avoid direct sunlight
– Permissible ambient temperature
at fixing position: 0 ... 50 °C at
max. 95 % relative air humidity
(non-condensing)
NOTICE!
Material damage to electrostatically
sensitive components
Components can be damaged or
destroyed by electrostatic voltages.
– Before any work, on electrostati‐
cally sensitive components, dis‐
connect the power supply.
–
When working on electrostatically
sensitive components, wear an
earthed anti-static wrist band.
– Always hold components by their
corners and never touch conduc‐
tors, ICs, etc.
– Only place components on anti-
static supports or the original
packaging.
Ablese- und Bedienposition
–
Das Gerät in einer günstigen
Ablese- und Bedienposition
(möglichst in Augenhöhe) mon‐
tieren
Montageposition
–
Ausreichend Freiraum für die
Kabel vorsehen
–
Für die ‘Parkstellung’ des
Reglers, nach oben mindestens
120 mm Platz freihalten
D1Cb mounting
22
