ProMinent DULCOMETER D1Cb - Opening the Device

3.4.1 Opening the device
Fig. 6: Opening the device
1. Loosen the 4 captive screws (1).
2. Lift the upper section of the device from the lower section (2). A wide flathead
screwdriver may be of assistance.
3. Insert the upper section with both guide rails into the lower section (3 and 4)
(parked position)
D1Cb mounting
28
