2.2.1 Block circuit diagram
NOTICE!
Connection of mV or mA sensors
The DULCOMETER
®
D1Cb / D1Cc is suitable for the connection of mV or mA sen‐
sors. It is not possible to connect mV and mA sensors simultaneously.
externer Speicher /
EEROM/Flash
mV Eingang /
mA Eingang /
Kontakteingang
Netzteil
Temperatureingang /
Relaisausgang 3 /
Relaisausgang 2 /
Relaisausgang 1 /
Kontaktausgang 1 /
Kontaktausgang 2 /
Stromausgang /
Fig. 1: Block circuit diagram
Functional description
