7.4 Complete Operating Menu / Description of All Measured Variables
The complete operating menu allows all controller parameters to be set. The following
overview shows the settings that can be selected:
Only with
feed forward control
Permanent display 1
Permanent display 2
only with control
(w = setpoint)
Only with limit value-,
or solenoid relay
Only with pumps
ppm
0.60
auto.: 30.0 °C
Only with
temperature
correction
Only with
mA output
mea. val 0.60ppm
feed fwd: 70 %
ctrlout: 59 %
w=
0.60 ppm
calibration
zero p.: 4.0 mA
slope:
6.50 mA/ppm
measured value
setting ?
correcting value
setting ?
pumps
setting ?
relay
setting ?
limits
setting ?
mA -output
setting ?
general setting
information
pause / feedfwd:
setting ?
A0017_GB
0.60 ppm
0.0 10.0
Permanent display
3
Only with control
control
setting ?
Fig. 37: Complete operating menu
Measured Variables and Operating Menus for Amperometric Sensors
