3.3 Installation - Control Panel Mounted (Optional)
CAUTION!
Dimensional variations
Possible consequence: material damage
– Photocopying the punched template can result in dimensional deviations
–
Use the dimensions shown in Fig. 4 and mark on the control panel
Fig. 4: Punched template, drawing number 3140-3 /not to scale
CAUTION!
Material thickness of control panel
Possible consequence: material damage
– The material thickness of the control panel must be at least 2 mm to ensure
secure fixing
D1Cb mounting
