13 Electrical Data
Mains connection
Nominal voltage range: 100 – 230 VAC ± 10 %
Frequency 50 – 60 Hz
Current consumption 95 – 250 mA
The mains connection is isolated from other switching parts by reinforced insulation. The
device has no mains switch; a fuse is fitted.
Power relay
Loading of switching contacts: 5 A; no inductive loads
Use protective RC circuit (optional) with
inductive loads
Alarm Relay
Loading of switching contacts: 5 A; no inductive loads
Use protective RC circuit (optional) with
inductive loads
Outputs galvanically isolated from other switching parts by reinforced insulation.
Digital input
Open circuit voltage: 6 V DC max.
Short circuit current: approx. 0.6 mA
Max.switching frequency: 500 Hz at 50% filling factor
Electrical Data
144
