4.1
DULCOMETER
®
D1Cc scope of supply
The following parts belong to the standard scope of supply of a DULCOMETER
®
series
D1Cc controller.
Identifier Quantity
D1Cc controller 1
Retaining bracket 4
Measured variable labels D1C/D2C 1
Operating Manual 1
General safety notes 1
4.2
Mounting - control panel installation DULCOMETER
®
D1Cc
CAUTION!
Dimensional variations
Possible consequence: material damage
– Photocopying the punched template can result in dimensional deviations
–
Use the dimensions according to Fig. 16 and mark on the control panel
CAUTION!
Material thickness of control panel
Possible consequence: material damage
– The material thickness of the control panel must be at least 2 mm to ensure
secure fixing
The device is designed for installation in a control panel. The housing corresponds to DIN
43700. The control panel opening for installation of the device is specified in DIN 43700.
We recommend a smaller opening. Fixing of the device is then better (less sideways
play) and the seal is uniformly compressed.
D1Cc mounting
41
