ProMinent DULCOMETER D1Cb - Zero Point Calibration (Standard Signal)

During the calibration, the DULCOMETER
®
D1Cb / D1Cc sets the control outputs to "0".
Exception: a basic load or a manual control value has been set. This remains active. The
mA standard signal outputs are frozen. The measured value frozen at the start of calibra‐
tion is suggested as a value. This value can be set using the arrow keys. Calibration is
only possible if the value is
≥ 2 % of the measuring range of the sensor or the measuring
device.
Error messages in the calibration menu
Fault message Condition Effect
Measured value gap too
small
∆ value < 5.0 %* Measured value is rejected;
Repeat calibration of the
measuring point!
∆ value <1.00 mA*
Refer to the operating manual of the respective sensor for all error messages and use
for troubleshooting.
* of the measuring range and measured value, see
Ä Table on page 105
9.8.1 Calibration of the Zero Point of the Standard Signal General
4.00 mA
16.00 mA
00003 m
3
/h
3.98 mA
16.02 mA
calibration
zero p.:
slope
Permanent display 1
calibration
mea. val
calibration
zero p.:
slope
D1C2-mA-029-GB
Fig. 53: Zero point calibration menu / shown with flow as the measured variable and the
measuring range 0...100 m
3
/h
The slope in the calibration menu is given as an mA value. This value should be
regarded as the mA/selected measuring unit.
Measured Variables and Operating Menus for the Standard Signal General
