5. Screw connec‐
tion M12 x 1.5
6. Lock nut
M12x1.5
1. Fit lock nut M12x1.5 (6) on the
inside
2. Fit screw connection M12x1.5 (5)
from the outside and tighten firmly
3.4.3
Electrical Installation (Control
Panel Mounted)
Proceed as described under "Electrical
Installation (Wall Mounted)". Refer to
Ä Chapter 3.4.2 ‘ Electrical Installation
(Wall Mounted) ’ on page 29
Only the rear row of threaded holes
(M20x1.5) should be used when the
device is mounted in a control panel. The
front row (M12x1.5) lies outside of the
control panel.
Connect up as per the electrical terminal
wiring diagram. Refer to
Ä Chapter 3.4.7
‘Terminal Wiring Diagram ’ on page 34
D1Cb mounting
30
