Not galvanically isolated from the mA and temperature inputs. Terminal for the connec‐
tion of an electrode for compensating for the potential of the measuring liquid
Temperature input
Temperature measuring range: 0...100 °C
Measuring flow: approx. 0.96 mA
Measuring accuracy: ± 0.5 % of measuring range
Overvoltage-resistant up to: ± 5 V
Short circuit-resistant Yes
For the connection of Pt100 or Pt1000 temperature sensors in 2-wire systems. A switch
is automatically made between Pt100 / Pt1000. Not galvanically isolated from the mA and
mV inputs.
Electrical Data
147
