No. Description
1
2 x Power Supply Units (Redundant PSU 1+1)
*Server requires 1 working PSU, with 1 redundant PSU. You must have at least one
active supply, installed, functioning and connected to AC. Only one of the PSUs is
allowed to be removed while the server is running.
2 I/O ports including two USB 3.0 ports, and one 1000BASE-T port (for BNC use only).
3
1 x PCI Express Slot 1 (on the riser card assembly)
*Supports Low prole and FHHL (Full High Half Length) PCIe cards
4
1 x LAN Mezzanine Card Slot
*Support for 1GbE x 2, 10GbE x2 or SFP+ x2
5
1 x PCI Express Slot 2 (on the riser card assembly)
*Supports Low prole and FHHL (Full High Half Length) PCIe cards
Rear Panel Hardware
1
2 3 54
6
Vess A6000 Series NVR Server Promise Technology
