Product Picture
Model A6120-AS A6120-MS A6120-RS
Form Factor 1U, 19” rack mount or desktop
Processor 2 x Intel Xeon E5-2620 v4 1 x Intel Xeon E5-2620 v4 1 x Intel Xeon E5-2603 v4
Memory 16/32GB DDR4 ECC 8GB DDR4 ECC 8GB DDR4 ECC
Internal Storage M.2 64G
SSD 0/2 (optional) N/A N/A
HDD 4 x 3.5” SATA (SAS optional)
Storage Expansion iSCSI & JBOD Up to 112 HDDs per node
RAID Levels 0,1,1E,3,5,6,10(0+1), 30,50,60
RAID Stripe Size 64K, 128K, 256K, 512K and 1MB
Max LUNs 256 logical drives per controller
Networking 1GbE x 4* 1GbE x 2* 1GbE x 2*
Power Supply Dual 650W Platinum
Dimension 710mm x 430mm x 43.5 mm
System Cooling 5 swappable fans
Preloaded OS WS2012 R2 WS2012 R2 Windows 10 Enterprise
Management Tools
GUI/SNMP via Ethernet/CLI&CLU via Ethernet or Graphics/OPAS Service via USB/SDK
or API for integration
Safety Certication FCC/CE/VCCI/RCM/BSMI/CB/KCC
Warranty 3-year Limited Warranty
Accessories Sliding Rail, 8GB DDR4 ECC Memory
*
Optional: 10G BaseT/SFP+/FC x 2
SpecIfIcatIonS
10
Vess A6000 Series NVR Server Promise Technology
