Promise Technology Vess A6120 - Installing an Add-On Card

1
1
1
2
Riser Card Assembly
instALLing An Add-on CArd
1. Remove the screws securing the riser card assembly on the chassis. Keep this screw for later use.
2. Lift up and remove the riser card assembly from the chassis.
3. Remove the screw securing the ller plate.
33
System Hardware AssemblyVess A6120 Product Manual
