Disk carrier release button
Drive carrier front view
remoVe driVe seCurity CoVer
To remove the security cover in front of the drive bays:
1. Use the tubular key to unlock the cover. Turn counterclockwise to unlock.
2. Slide the cover to the left about 4 mm.
3. Pull the cover straight back to remove. Be careful not to drop the cover
Follow these steps to install the hard disks:
1. Press the drive carrier release button. The handle springs open.
2. Grasp the handle and gently pull the empty drive carrier out of the enclosure.
Cautions
Swing open the drive carrier handle before you insert the drive
carrier into the enclosure.
To avoid hand contact with an electrical hazard, remove only one
drive carrier a time.
17
IntroductionVess A6120 Product Manual
