Fan Mount
Mounting Hole
SyStem Fan
rePLACing the system FAn
1. Unplug the fan connecter and remove the failed fan.
2. Align the mounting holes on the fan bar with the fan mounts on the replacement fan.
3. Gently place the fan on the fan bar. Make sure the fan is well seated.
4. Connect the end of the fan cable to the fan connector.
39
System Hardware AssemblyVess A6120 Product Manual
