RJ-45 Plug
Release Module
4
5
3. Use screws to secure the mezzanine card to the motherboard standoffs.
4. Tighten the screws to secure the matching I/O module to the chassis. Install the RJ-45 plug release
module instead for the M540 mezzanine card.
5. If you use the RJ-45 plug release module, simply press it to release plugs.
