If you select both interfaces you can send messages to the PAA20+ using
any of the Serial or Ethernet interfaces.
Port Number: Field to input the port number in which you want or receive
the messages when using the Ethernet interface.
Default port is 10001.
Output codes:
These fields set the messages that the PAA20+ will receive from the server
to perform the associated actions.
See Figure 7.2.5.A and Figure 7.2.5.C, they show the top and the bottom
of the Automation Output Configuration page. Every action listed in the left
column is associated with the character string inside the textbox. When the
PAA20+ receives a valid message followed by a valid “Message Terminator” it
executes the associated action.
There are three types of actions:
● On: Activates de associated relay output.
● Off: Deactivates the associated relay output.
● Pulse: Activates the associated relay output for a time specified in the
“T:” field.
o T: Pulse duration in milliseconds for the output. Value may be
set from 1ms to 9999ms. Pulses shorter than 20ms do not
ensure activation of the relay contact. Default value is 500ms
(0.5s).
Messages in the Figures are the factory default messages, compatible with
both Dolby and Doremi configuration files available at the FTP:
ftp://manual:proyecson@ftp3.proyecson.com/manual/paa20+. To change
messages, write down new ones in the associated textbox and press the save
button to the right.
INSTALLATION MANUAL: PAA20+ V 2.0 (10/2021) 30
