Figure 7.2.5D

Actual firmware version limits the message length to seven characters

in these fields.

Should you modify the factory default messages, use of the provided

Dolby and Doremi server configuration files is not advisee because messages

will not match.

INSTALLATION MANUAL: PAA20+ V 2.0 (10/2021) 32
