5. Click on the “Automation” button to go to the Automation screen,

Figure 8.3.1D.

Figure 8.5.1D

6. Select “Devices” tab to access the “Devices” screen, Figure 8.5.1E.

Figure 8.5.1E

INSTALLATION MANUAL: PAA20+ V 2.0 (10/2021) 93
