COMMUNICATIONS PROTOCOL Cubiscan 325 command set
CubiScan 325 Service Manual 62
Key coordinates
This command causes the Cubiscan 325 to accept keyboard input in touch pad coordinates. The
X coordinate is horizontal, the Y coordinate is vertical.
Pos Len Description Type Range ASCII
Command format
1 1 Start of text Control (STX) 02h
2 1 Key command Alpha (k) 6Bh
3 4 X coordinate Numeric 0000-9999
7 1 Comma Alpha (,) 2Ch
8 4 Y coordinate Numeric 0000-9999
12 1 End of text Control (ETX) 03h
13 1 Carriage return Control (CR) 0Dh
14 1 Line feed Control (LF) 0Ah
Acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Key command Alpha (k) 6Bh
3 1 Acknowledge Alpha (A) 41h
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
Negative acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Key command Alpha (k) 6Bh
3 1 Neg. acknowledge Alpha (N) 4Eh
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
