COMMUNICATIONS PROTOCOL TCP/IP communications setup command set
CubiScan 325 Service Manual 77
issued when the measuring field is free of objects! Never issue this command when an object is
present in the measuring field.
TCP/IP communications setup command set
This section describes the commands recognized by the Cubiscan 325 to set up the Cubiscan
325 for communications with a network using the TCP/IP protocol.
You can use the Qbit, QbitTCP software to configure the Cubiscan 325 for TCP/IP
communications. Contact Cubiscan for information.
Configuration of the Cubiscan 325 for TCP/IP communication is performed through the RS-232-C
serial communications port using the following commands.
Pos Len Description Type Range ASCII
Command format
1 1 Start of text Control (STX) 02h
2 1 Zero command Alpha (Z) 5Ah
3 1 End of text Control (ETX) 03h
4 1 Carriage return Control (CR) 0Dh
5 1 Line feed Control (LF) 0Ah
Acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Zero command Alpha (Z) 5Ah
3 1 Acknowledge Alpha (A) 41h
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
Negative acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Zero command Alpha (Z) 5Ah
3 1 Neg. acknowledge Alpha (N) 4Eh
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
