COMMUNICATIONS PROTOCOL Cubiscan 325 command set
CubiScan 325 Service Manual 68
Scrape screen
This command causes the Cubiscan 325 to save the current touchscreen image to the file
cs125isc.bmp.
Serial get
This command causes the Cubiscan 325 to transfer a file from the virtual file system via RS-232 or
USB packets.
Pos Len Description Type Range ASCII
Command format
1 1 Start of text Control (STX) 02h
2 1 Scrape command Alpha (a) 61h
3 1 End of text Control (ETX) 03h
4 1 Carriage return Control (CR) 0Dh
5 1 Line feed Control (LF) 0Ah
Acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Scrape command Alpha (a) 61h
3 1 Acknowledge Alpha (A) 41h
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
Negative acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Scrape command Alpha (a) 61h
3 1 Neg. acknowledge Alpha (N) 4Eh
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
Command format
1 1 Start of text Control (STX) 02h
2 1 Serial get command Alpha (g) 67h
31
Mode Numeric (1=Read, 4=Ack,
5=Error)
