COMMUNICATIONS PROTOCOL TCP/IP communications setup command set
CubiScan 325 Service Manual 82
Read MAC address
This command is used to read the current MAC address setting from the Cubiscan 325.
6 1 Carriage return Control (CR) 0Dh
7 1 Line feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
Command format
1 1 Start of text Control (STX) 02h
2 1 Read command Alpha (~) 7Eh
3 1 MAC address command Alpha (M) 4Dh
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
Acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Read command Alpha (~) 7Eh
3 1 MAC address command Alpha (M) 4Dh
4 1 Acknowledge Alpha (A) 41h
512
MAC address Alpha 000000000000-
FFFFFFFFFFFF
17 1 End of text Control (ETX) 03h
18 1 Carriage return Control (CR) 0Dh
19 1 Line feed Control (LF) 0Ah
Negative acknowledge format
Pos Len Description Type Range ASCII
1 1 Start of text Control (STX) 02h
2 1 Read command Alpha (~) 7Eh
3 1 MAC address command Alpha (M) 4Dh
4 1 Neg. acknowledge Alpha (N) 4Eh
5 1 End of text Control (ETX) 03h
6 1 Carriage return Control (CR) 0Dh
7 1 Line feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
