COMMUNICATIONS PROTOCOL Cubiscan 325 command set
CubiScan 325 Service Manual 55
Dimension units
This command is used to set the dimension units to either English (inches) or metric (centimeters)
mode.
62 1 Line feed Control (LF) 0Ah
Negative acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Measure command Alpha (M) 4Dh
3 1 Neg. acknowledge Alpha (N) 4Eh
41
Cubiscan/Host
originated
Alpha (C/H) 43h or 48h
51
Corner sensor/Measure/
Zero error
Alpha (C/M/Z) 43h or 4Dh
6 1 End of text Control (ETX) 03h
7 1 Carriage return Control (CR) 0Dh
8 1 Line feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
Command format
1 1 Start of text Control (STX) 02h
2 1 Dim. unit command Alpha (") 22h
3 1 English or metric Alpha (E/M) 45h or 4Dh
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
Acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Dim. unit command Alpha (") 22h
3 1 Acknowledge Alpha (A) 41h
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
Negative acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Dim. unit command Alpha (") 22h
Pos Len Description Type Range ASCII
