COMMUNICATIONS PROTOCOL Cubiscan 325 command set
CubiScan 325 Service Manual 69
Serial loop back
This command causes the Cubiscan 325 to report a command code to the display.
4n
Index or filename Alpha 0000-9999 or
filename
4+n 1 End of text Control (ETX) 03h
5+n 1 Carriage return Control (CR) 0Dh
6+n 1 Line feed Control (LF) 0Ah
Acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Serial get command Alpha (g) 67h
3 1 Data mode Numeric (3) 33h
4 4 Index Numeric (0000-9999)
8 3 Size Numeric (000-500)
11 n Data Binary
11+n 1 End of text Control (ETX) 03h
12+n 1 Carriage return Control (CR) 0Dh
13+n 1 Line feed Control (LF) 0Ah
Negative acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Serial get command Alpha (g) 67h
3 1 Neg. acknowledge Alpha (N) 4Eh
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
Command format
1 1 Start of text Control (STX) 02h
2 1 Loop back command Alpha (P) 50h
3 1 End of text Control (ETX) 03h
4 1 Carriage return Control (CR) 0Dh
5 1 Line feed Control (LF) 0Ah
Acknowledge format
1 1 Start of text Control (STX) 02h
Pos Len Description Type Range ASCII
