COMMUNICATIONS PROTOCOL TCP/IP communications setup command set
CubiScan 325 Service Manual 79
Set gateway address
This command is used to set the network gateway address on the Cubiscan 325. It can be the
address of a network server or router and is expressed in “dot” notation. Consult your network
administrator to obtain the network gateway address.
6+n 1 Carriage return Control (CR) 0Dh
7+n 1 Line feed Control (LF) 0Ah
Negative acknowledge format
Pos Len Description Type Range ASCII
1 1 Start of text Control (STX) 02h
2 1 Read command Alpha (~) 7Eh
31
Gateway address
command
Alpha (G) 47h
4 1 Neg. acknowledge Alpha (N) 4Eh
5 1 End of text Control (ETX) 03h
6 1 Carriage return Control (CR) 0Dh
7 1 Line feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
Command format
1 1 Start of text Control (STX) 02h
2 1 Set command Alpha (@) 40h
3 1 Gateway address command Alpha (G) 47h
4
7-15
or n
IP address Alpha (0.0.0.0) to
(255.255.255.255)
4+n 1 End of text Control (ETX) 03h
5+n 1 Carriage return Control (CR) 0Dh
6+n 1 Line feed Control (LF) 0Ah
Acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Set command Alpha (@) 40h
3 1 Gateway address command Alpha (G) 47h
4 1 Acknowledge Alpha (A) 41h
5 1 End of text Control (ETX) 03h
6 1 Carriage return Control (CR) 0Dh
Pos Len Description Type Range ASCII
