COMMUNICATIONS PROTOCOL TCP/IP communications setup command set
CubiScan 325 Service Manual 85
number between 49152 and 65535 to avoid conflicts. Consult your network administrator to
select the port number.
Read subnet address
This command is used to read the current subnet address setting from the Cubiscan 325.
Pos Len Description Type Range ASCII
Command format
1 1 Start of text Control (STX) 02h
2 1 Set command Alpha (@) 40h
3 1 Port command Alpha (P) 50h
4 1-5 or n Port Alpha (0) to (65535)
4+n 1 End of text Control (ETX) 03h
5+n 1 Carriage return Control (CR) 0Dh
6+n 1 Line feed Control (LF) 0Ah
Acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Set command Alpha (@) 40h
3 1 Port command Alpha (P) 50h
4 1 Acknowledge Alpha (A) 41h
51End of text Control(ETX) 03h
6 1 Carriage return Control (CR) 0Dh
7 1 Line feed Control (LF) 0Ah
Negative acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Set command Alpha (@) 40h
3 1 Port command Alpha (P) 50h
4 1 Neg. acknowledge Alpha (N) 4Eh
51End of text Control(ETX) 03h
6 1 Carriage return Control (CR) 0Dh
7 1 Line feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
Command format
1 1 Start of text Control (STX) 02h
2 1 Read command Alpha (~) 7Eh
3 1 Subnet address command Alpha (N) 4Eh
