COMMUNICATIONS PROTOCOL Cubiscan 325 command set
CubiScan 325 Service Manual 63
Location identification
This command is used to set the Cubiscan 325 location identification. The location identification
is a six-digit code which uniquely identifies the Cubiscan 325 within the user’s operation. This
location identification is included in each measurement packet. This data is stored in permanent
memory and need only be set once for each Cubiscan 325.
Model
This command causes the Cubiscan 325 to change its current model designation. The Cubiscan
325 = 08.
Pos Len Description Type Range ASCII
Command format
1 1 Start of text Control (STX) 02h
2 1 Location ID command Alpha (L) 4Ch
3 6 Location ID Alpha 000000-ZZZZZ
9 1 End of text Control (ETX) 03h
10 1 Carriage return Control (CR) 0Dh
11 1 Line feed Control (LF) 0Ah
Acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Location ID command Alpha (L) 4Ch
3 1 Acknowledge Alpha (A) 41h
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
Negative acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Location ID command Alpha (L) 4Ch
3 1 Neg. acknowledge Alpha (N) 4Eh
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
Command format
1 1 Start of text Control (STX) 02h
2 1 Model command Alpha (!) 21h
