COMMUNICATIONS PROTOCOL TCP/IP communications setup command set
CubiScan 325 Service Manual 81
Set IP address
This command is used to set the Cubiscan 325 IP address. The IP address, or Internet address, is
usually expressed in “dot” notation; for example, “121.43.6.234.” The first three groups of
numbers (e.g., 121.43.6) are usually specific to the network to which you are connecting. The last
number (e.g., 234) is specific to a particular Cubiscan 325. Consult your network administrator to
obtain an available IP address.
4 1 Neg. acknowledge Alpha (N) 4Eh
5 1 End of text Control (ETX) 03h
6 1 Carriage return Control (CR) 0Dh
7 1 Line feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
Command format
1 1 Start of text Control (STX) 02h
2 1 Set command Alpha (@) 40h
3 1 IP address command Alpha (I) 49h
4
7-15
or n
IP address Alpha (0.0.0.0) to
(255.255.255.255)
4+n 1 End of text Control (ETX) 03h
5+n 1 Carriage return Control (CR) 0Dh
6+n 1 Line feed Control (LF) 0Ah
Acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Set command Alpha (@) 40h
3 1 IP address command Alpha (I) 49h
4 1 Acknowledge Alpha (A) 41h
5 1 End of text Control (ETX) 03h
6 1 Carriage return Control (CR) 0Dh
7 1 Line feed Control (LF) 0Ah
Negative acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Set command Alpha (@) 40h
3 1 IP address command Alpha (I) 49h
4 1 Neg. acknowledge Alpha (N) 4Eh
5 1 End of text Control (ETX) 03h
Pos Len Description Type Range ASCII
