COMMUNICATIONS PROTOCOL TCP/IP communications setup command set
CubiScan 325 Service Manual 86
Set subnet address
This command is used to set the Cubiscan 325 subnet address. The subnet (sub-network) is a
separate part of an organization’s network. A subnet address tells the network’s router where on
the network to send incoming packets of information.
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
Acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Read command Alpha (~) 7Eh
3 1 Subnet address command Alpha (N) 4Eh
4 1 Acknowledge Alpha (A) 41h
5
7-15
or n
IP address Alpha (0.0.0.0) to
(255.255.255.255)
5+n 1 End of text Control (ETX) 03h
6+n 1 Carriage return Control (CR) 0Dh
7+n 1 Line feed Control (LF) 0Ah
Negative acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Read command Alpha (~) 7Eh
3 1 Subnet address command Alpha (N) 4Eh
4 1 Neg. acknowledge Alpha (N) 4Eh
5 1 End of text Control (ETX) 03h
6 1 Carriage return Control (CR) 0Dh
7 1 Line feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
Command format
1 1 Start of text Control (STX) 02h
2 1 Set command Alpha (@) 40h
3 1 IP address command Alpha (N) 4Eh
4
7-15
or n
IP address Alpha (0.0.0.0) to
(255.255.255.255)
4+n 1 End of text Control (ETX) 03h
5+n 1 Carriage return Control (CR) 0Dh
Pos Len Description Type Range ASCII
