COMMUNICATIONS PROTOCOL Cubiscan 325 command set
CubiScan 325 Service Manual 74
Values
This command causes the Cubiscan 325 to report various internal parameters. This is useful for
troubleshooting.
Pos Len Description Type Range ASCII
Command format
1 1 Start of text Control (STX) 02h
2 1 Values command Alpha (V) 56h
3 1 End of text Control (ETX) 03h
4 1 Carriage return Control (CR) 0Dh
5 1 Line feed Control (LF) 0Ah
Acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Values command Alpha (V) 56h
3 1 Acknowledge Alpha (A) 41h
4 4 Length DBW Numeric 00.0-99.9
8 1 Comma Alpha (,) 2Ch
9 4 Width DBW Numeric 00.0-99.9
13 1 Comma Alpha (,) 2Ch
14 4 Height DBW Numeric 00.0-99.9
18 1 Comma Alpha (,) 2Ch
19 4 Length CPI Numeric 0000-9999
23 1 Comma Alpha (,) 2Ch
24 4 Width CPI Numeric 0000-9999
28 1 Comma Alpha (,) 2Ch
29 4 Height CPI Numeric 0000-9999
33 1 Comma Alpha (,) 2Ch
34 4 Length blanking Numeric 0.00-9.99
38 1 Comma Alpha (,) 2Ch
39 4 Width blanking Numeric 0.00-9.99
43 1 Comma Alpha (,) 2Ch
44 4 Height blanking Numeric 0.00-9.99
48 1 Comma Alpha (,) 2Ch
49 4 Length gain Numeric 00.0-99.9
53 1 Comma Alpha (,) 2Ch
54 4 Width gain Numeric 00.0-99.9
58 1 Comma Alpha (,) 2Ch
To Next Page
