COMMUNICATIONS PROTOCOL Cubiscan 325 command set
CubiScan 325 Service Manual 75
59 4 Height gain Numeric 00.0-99.9
63 1 Comma Alpha (,) 2Ch
64 2 Length pulses Numeric 00-99
66 1 Comma Alpha (,) 2Ch
67 2 Width pulses Numeric 00-99
69 1 Comma Alpha (,) 2Ch
70 2 Height pulses Numeric 00-99
72 1 Comma Alpha (,) 2Ch
73 3 Length wait time Numeric 000-999
76 1 Comma Alpha (,) 2Ch
77 3 Width wait time Numeric 000-999
80 1 Comma Alpha (,) 2Ch
81 3 Height wait time Numeric 000-999
84 1 Comma Alpha (,) 2Ch
85 4
Model number Alpha “50” /
“100L”
89 1 Comma Alpha (,) 2Ch
90 3
Scale capacity - English Numeric 000-999 50=10,20,30
100=100,150,20
1
93 1 Comma Alpha (,) 2Ch
94 5 Firmware version Alpha 0.000-9.999
99 1 Future growth Alpha Space 0h
100 2 Firmware build number Numeric 00-99
102 1 Comma Alpha (,) 2Ch
103 4 FPGA build number Numeric 0.00-9.99
107 1 Comma Alpha (,) 2Ch
108 8
Serial number Numeric 00000000-
99999999
116 1 Comma Alpha (,) 2Ch
117 10 Future growth Alpha Space 0h
127 1 End of text Control (ETX) 03h
128 1 Carriage return Control (CR) 0Dh
129 1 Line feed Control (LF) 0Ah
Negative acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Values command Alpha (V) 56h
Pos Len Description Type Range ASCII
