Quantronix CUBISCAN 325 - Flash Firmware; Gate Measure

COMMUNICATIONS PROTOCOL Cubiscan 325 command set
CubiScan 325 Service Manual 59
Flash firmware
This command causes the Cubiscan 325 to flash file cs125.bin stored on the SD card.
Gate measure
The Cubiscan 325 will automatically send measurement data upon completion of a gate
measurement. The dimensions of the object that was measured will be sent.
Pos Len Description Type Range ASCII
Command format
1 1 Start of text Control (STX) 02h
2 1 Flash command Alpha (f) 66h
3 1 End of text Control (ETX) 03h
4 1 Carriage return Control (CR) 0Dh
5 1 Line feed Control (LF) 0Ah
Acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Flash command Alpha (f) 66h
3 1 Acknowledge Alpha (A) 41h
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
Negative acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Flash command Alpha (f) 66h
3 1 Neg. acknowledge Alpha (N) 4Eh
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
Acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Measure command Alpha (m) 6Dh
3 1 Acknowledge Alpha (A) 41h
